Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	37
Nominal Power Handling (Pnom)(W) :	60
Max Power Handling (Pmax)(W) :	120
Sensitivity (2.83v/1m)(dB) :	88
Weight (M)(Kg) :	2.9
VC Diameter (mm) :	35
DC (Re)(Ω) :	6.5
VC Length (H)(mm) :	17.5
VC Former :	SV
VC Frame :	Kapton
Magnet System :	Shielded
Magnet Former :	Ferrite
Force Factor (BL)(N/A) :	10.3
Gap Height (He)(mm) :	7.5
Linear Excursion (Xmax)(mm) :	5
Suspension Compliance (Cms)(uM/N) :	593.7
Mechanical Q (Qms) :	4.71
Electrical Q (Qes) :	0.44
Total Q (Qts) :	0.4
Moving Mass (Mms)(g) :	30.5
Effective Piston Area (Sd)(m2) :	0.0214
Equivalent Air Volume (Vas)(L) :	38.8
Cabinet Type :	Vented
Recommended Box Volume(Vb)(L) :	35
Tuning Frequency(Fb)(Hz) :	40
-3dB Cut-Off Frequency(F3)(Hz) :	38
