Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	52
Nominal Power Handling (Pnom)(W) :	35
Max Power Handling (Pmax)(W) :	70
Sensitivity (2.83v/1m)(dB) :	86
Weight (M)(Kg) :	1.6
VC Diameter (mm) :	25
DC (Re)(Ω) :	6.5
VC Length (H)(mm) :	10.4
VC Former :	CCAW
VC Frame :	Kapton
Magnet System :	Shielded
Magnet Former :	Ferrite
Force Factor (BL)(N/A) :	8.3
Gap Height (He)(mm) :	5
Linear Excursion (Xmax)(mm) :	2.7
Suspension Compliance (Cms)(uM/N) :	828
Mechanical Q (Qms) :	4.31
Electrical Q (Qes) :	0.36
Total Q (Qts) :	0.33
Moving Mass (Mms)(g) :	11.5
Effective Piston Area (Sd)(m2) :	0.0079
Equivalent Air Volume (Vas)(L) :	7.3
Cabinet Type :	Vented
Recommended Box Volume(Vb)(L) :	8
Tuning Frequency(Fb)(Hz) :	50
-3dB Cut-Off Frequency(F3)(Hz) :	47
