CarAudio-BG

Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	26
Nominal Power Handling (Pnom)(W) :	100
Max Power Handling(Pmax)(W) :	200
Sensitivity (2.83v/1m)(dB) :	89
Weight (M)(Kg) :	6.2
VC Diameter (mm) :	50
DC (Re)(Ω) :	6.5
VC Length (H)(mm) :	22
VC Former :	SV
VC Frame :	Kapton
Magnet System :	Outside
Magnet Former :	Ferrite
Force Factor (BL)(N/A) :	16.1
Gap Height (He)(mm) :	10
Linear Excursion (Xmax)(mm) :	6
Suspension Compliance (Cms)(uM/N) :	387
Mechanical Q (Qms) :	6.21
Electrical Q (Qes) :	0.39
Total Q (Qts) :	0.36
Moving Mass (Mms)(g) :	99.9
Effective Piston Area (Sd)(m2) :	0.0515
Equivalent Air Volume (Vas)(L) :	145.6
Cabinet Type :	Vented
Recommended Box Volume(Vb)(L) :	60
Tuning Frequency(Fb)(Hz) :	30
-3dB Cut-Off Frequency(F3)(Hz) :	35
