Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	28
Nominal Power Handling (Pnom)(W) :	100
Max Power Handling(Pmax)(W) :	200
Sensitivity (2.83v/1m)(dB) :	89
Weight (M)(Kg) :	4.5
VC Diameter (mm) :	50
DC (Re)(Ω) :	6.5
VC Length (H)(mm) :	22
VC Former :	SV
VC Frame :	Kapton
Magnet System :	Outside
Magnet Former :	Ferrite
Force Factor (BL)(N/A) :	16.2
Gap Height (He)(mm) :	10
Linear Excursion (Xmax)(mm) :	6
Suspension Compliance (Cms)(uM/N) :	420.2
Mechanical Q (Qms) :	5.12
Electrical Q (Qes) :	0.33
Total Q (Qts) :	0.31
Moving Mass (Mms)(g) :	72.6
Effective Piston Area (Sd)(m2) :	0.0363
Equivalent Air Volume (Vas)(L) :	78.6
Cabinet Type :	Vented
Recommended Box Volume(Vb)(L) :	60
Tuning Frequency(Fb)(Hz) :	35
-3dB Cut-Off Frequency(F3)(Hz) :	33
