Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	32
Nominal Power Handling (Pnom)(W) :	150
Max Power Handling(Pmax)(W) :	300
Sensitivity (2.83v/1m)(dB) :	86
Weight (M)(Kg) :	3.5
VC Diameter (mm) :	100
DC (Re)(Ω) :	6.5
VC Length (H)(mm) :	23.5
VC Former :	CCAW
VC Frame :	Kapton
Magnet System :	Inside
Magnet Former :	Neodymium
Force Factor (BL)(N/A) :	12.9
Gap Height (He)(mm) :	7
Linear Excursion (Xmax)(mm) :	8.3
Suspension Compliance (Cms)(uM/N) :	457.8
Mechanical Q (Qms) :	4.36
Electrical Q (Qes) :	0.44
Total Q (Qts) :	0.4
Moving Mass (Mms)(g) :	53.1
Effective Piston Area (Sd)(m2) :	0.0241
Equivalent Air Volume (Vas)(L) :	37.8
Cabinet Type :	Vented
Recommended Box Volume(Vb)(L) :	30
Tuning Frequency(Fb)(Hz) :	35
-3dB Cut-Off Frequency(F3)(Hz) :	35
