Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	43
Nominal Power Handling (Pnom)(W) :	60
Max Power Handling(Pmax)(W) :	120
Sensitivity (2.83v/1m)(dB) :	85
Weight (M)(Kg) :	1.7
VC Diameter (mm) :	76 CCAW
DC Resistance(Ω) :	6.5
VC Length (H)(mm) :	15.5
VC Frame :	Kapton
Magnet System :	Shielded
Magnet Former :	Neodymium
Force Factor (BL)(N/A) :	8.9
Gap Height (He)(mm) :	5
Linear Excursion (Xmax)(mm) :	5.3
Suspension Compliance (Cms)(uM/N) :	647
Mechanical Q (Qms) :	5.21
Electrical Q (Qes) :	0.49
Total Q (Qts) :	0.45
Moving Mass (Mms)(g) :	21.9
Effective Piston Area (Sd)(m2) :	0.0121
Equivalent Air Volume (Vas)(L) :	13.5
Cabinet Type :	Vented
Recommended Box Volume(Vb)(L) :	10
Tuning Frequency(Fb)(Hz) :	44
-3dB Cut-Off Frequency(F3)(Hz) :	44
