Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	52
Nominal Power Handling (Pnom)(W) :	60
Max Power Handling(Pmax)(W) :	120
Sensitivity (2.83v/1m)(dB) :	83
Weight (M)(Kg) :	1.8
VC Diameter (mm) :	76
DC (Re)(Ω) :	6.5
VC Length (H)(mm) :	15.5
VC Former :	CCAW
VC Frame :	Kapton
Magnet System :	Insides
Magnet Former :	Neodymium
Force Factor (BL)(N/A) :	9
Gap Height (He)(mm) :	6
Linear Excursion (Xmax)(mm) :	4.8
Suspension Compliance (Cms)(uM/N) :	522
Mechanical Q (Qms) :	3.07
Electrical Q (Qes) :	0.42
Total Q (Qts) :	0.37
Moving Mass (Mms)(g) :	17.3
Effective Piston Area (Sd)(m2) :	0.0087
Equivalent Air Volume (Vas)(L) :	5.6
Cabinet Type :	Vented
Recommended Box Volume(Vb)(L) :	8
Tuning Frequency(Fb)(Hz) :	48
-3dB Cut-Off Frequency(F3)(Hz) :	45
