Nominal Impedance (Z)(Ω) :	8
Resonance Frequency (Fs)(Hz) :	130
Nominal Power Handling (Pnom)(W) :	15
Max Power Handling (Pmax)(W) :	30
Sensitivity (2.83v/1m)(dB) :	84
Weight (M)(Kg) :	0.53
VC Diameter (mm) :	20
DC (Re)(Ω) :	6.5
VC Length (H)(mm) :	8.1
VC Former :	SV
VC Frame :	Kapton
Magnet System :	Shielded
Magnet Former :	Ferrite
Force Factor (BL)(N/A) :	2.98
Gap Height (He)(mm) :	3
Linear Excursion (Xmax)(mm) :	2.55
Suspension Compliance (Cms)(uM/N) :	671
Mechanical Q (Qms) :	3.864
Electrical Q (Qes) :	1.269
Total Q (Qts) :	0.955
Moving Mass (Mms)(g) :	2.057
Effective Piston Area (Sd)(m2) :	0.003
Equivalent Air Volume (Vas)(L) :	0.869
Cabinet Type :	Sealed
Recommended Box Volume(Vb)(L) :	2
Tuning Frequency(Fb)(Hz) :	---
-3dB Cut-Off Frequency(F3)(Hz) :	80
